The specification of 40ft container loading trailer 2 axle flatbed semi trailer for sale. Factory sale 2 axle flatbed trailer flatbed Semi-Trailer , 3 axle 40ft container semi trailer 35tons 40tons flatbed semi trailer for sale
> Semi Trailer Features:
1.Apply to the transport loose cargo light, soft, with a low center of gravity and light weight, the quality of the utilization factor, carrying capacity and other characteristics
2. Overall assembly and disassembly convenient, can be more than one car, van, car warehouse gate, tailgate car at the same time.
3.Innovative design, tailored to local transport environment analysis on the basis of full understanding of, learn from the advanced design concept, many innovative.
4.advanced means of production technology and perfect testing equipment to protect the the product overall structure is reasonable, reliable performance.
5. frame body Q345B high strength structure steel, automatic submerged arc welding throughout beams, and other cross-section main stringers structure for optimum carrying effect.
6. Well-known brand axles, suspension systems, high performance, and reliable to use, to ensure the good performance of the vehicle.
7.Full braking and electrical systems at home and abroad in accordance with ISO standard, optional ABS system, braking, lighting is absolutely safe and reliable.
8.frame overall spray primer treatment, paint spraying fine surface quality of maritime anti-corrosion standards.
9.Products fully comply with relevant national standard GB1589, GB/T6420, at the same time to meet the individual needs of customers.
DIMENSIONS
| Vehicle Name |
3 or 2 axle flatbed semi-trailer |
| Vehicle model |
9400TDP |
| Loading capacity |
40T |
| Function |
2*20ft or 1*40ft container |
| Dimension Parameter |
| Overall length (mm) |
12500 |
| Overall width (mm) |
2500 |
| Overall height (mm) |
1560 |
| Wheelbase (mm) |
6400+1310+1310 |
| Front / rear suspension (mm) |
-/2000 |
| Front / rear tread (mm) |
-/1840/1840/1840 |
| Weight Parameter |
| GVW (kg) |
40000 |
| Payload weight (kg) |
34000 |
| Kerb weight (kg) |
6000 |
| Others |
| Spring leaf No. |
-/10/10/10 |
| Tyre type |
11.00R20 |
| Tyre No. |
12 |
| Suspension |
3 axle mechanism suspension |
| Axle |
3* 13T FUWA |
| Landing gear |
Jost 28T, two-speed, manual operation |
| Material of main beam |
16Mn |
| Main beam |
Height: 500mm, top flange: 16mm, bottom flange:16mm, middle flange: 8mm |
| Platform plate |
3mm |
| Kingpin size |
2” or 3.5” |
| Electrical |
24V, 7 pin socket |
| Equipment |
Double tyre carrier, one tool box |
| Painting |
Sand blasting before painting, one coat of primer, anti-corrosion, two coat of finish painting, color can be choose as client request. |
The detailed pictures:
